LIFT & SLIDE T46

Provides High Functionality & Top Performance | Gives Maximum Visibility

The Engineering

The Lift & Slide T46 system is engineered for both functionality and ease of use, making it a popular choice among architects and builders. This system offers a robust sliding mechanism ideal for large doors, providing effortless operation and top-notch thermal insulation.

The Engineering

Key Highlights

Quiet and Seamless Operation

Designed with a sophisticated sliding mechanism, the T46 enables smooth, quiet movement, making it perfect for residential and commercial applications where silence is valued.

Thermal Break Technology

By using aluminum profiles with a thermal break, the T46 effectively minimizes heat loss and gain, helping maintain comfortable indoor temperatures while reducing energy costs.

Enhanced Security

Equipped with a heavy-duty locking system featuring multiple locking points and a cylinder lock option, it can support weights of up to 300kg. This enhances security, making it an excellent anti-burglary solution.

Technical Specifications

Slim, Minimalist Profile

The T46’s interlocking profile width of just 30mm maximizes the view while maintaining structural strength.

Large Glass Capacity

Panels can reach widths of 1.8 meters and heights of up to 2.8 meters, creating an expansive, uninterrupted view.

Concealed Frame for Seamless Transition

The T46’s hidden bottom track is perfect for creating a transition from indoor to outdoor spaces, keeping the floor level continuous and the threshold invisible.

T46 | LIFT & SLIDE SYSTEM

Thermally Insulated

FRAME WIDTH	130 MM
FRAME HEIGHT	45 MM
SASH WIDTH	75 MM
SASH HEIGHT	53 MM
INTERLOCKING PROFILE WIDTH	30 MM
MAXIMUM HEIGHT OF SASH	2.8 M
SASH WEIGHT	300 KG
GLAZING	30, 32 MM
INSULATION	PVC, POLYMIDE
SILL	CONCEALED BOTTOM RAIL
